| CPU | Qualcomm SnapdragonTM 660 octa-core, 2.2 GHz |
| Operating System | Upgradeable to Android 14 |
| Memory | 3 GB RAM/32 GB Flash |
| Security | Product is FIPS 140-2 validated. This security feature can be enabled on select configurations through a custom SKU request. Product supports Secure Boot, Verified Boot |
| User Environment | |
| Operating Temp. | -22° F to 122° F/-30° C to +50° C |
| Storage Temp. | -40° F to 158° F/-40° C to +70° C |
| Humidity | 5% - 95% non condensing |
| Drop Spec. | Multiple 4 ft./1.2 m drop to concrete across operating temperature per MIL-STD 810G |
| Tumble Spec. | 1,000 tumbles @ 1.6 ft./0.5 m; meets and exceeds
IEC tumble specifications |
Sealing
| IP65 per applicable IEC sealing specifications |
| Vibration | 4g PK Sine (5Hz to 2kHz); 0.04g 2/Hz Random (20 Hz to 2 kHz); 60 minutes duration per axis, 3 axis |
| Electrostatic Discharge (ESD) | +/-15 kV air discharge, +/-8 kV direct/indirect discharge |
| | |
| Interactive Sensor Technology (IST) | |
| Motion Sensor | 3-axis accelerometer with MEMS Gyro |
Data Capture | |
| Scanning | Corded ring scanners: RS4000 and RS5000
Bluetooth ring scanners: RS5100 and RS6000 with NFC tap to pair |
| NFC | ISO14443 Type A and B: FeliCa and ISO 15693 cards.
P2P mode and Card Emulation via Host (HCE) support |
| Wireless LAN | |
| WLAN Radio | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/w/v/mc; 2x2 MU-MIMO
Wi-Fi™ certified; Dual Band Simultaneous; IPv4, IPv6 |
| Data Rates | 2.4GHz: 802.11b/g/n — 20MHz, 40MHz - up to 300 Mbps
5GHz: 802.11a/n/ac — 20MHz, 40MHz, 80MHz - up to 866.7 Mbps |
| Operating Channels | Channel 1-13 (2412-2472 MHz): 1,2,3,4,5,6,7,8,9,10,11,12,13
Channel 36-165 (5180-5825MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency. |
Security and Encryption
| WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP and EAP-PWD; WPA3 Enterprise 192-bit Mode (GCMP-256) — EAP-TLS; Enhanced Open (OWE) |
Certifications
| WFA (802.11n, 80211ac, WPA2-Personal, WPA3-Personal, WPA2-Enterprise, WPA3-Enterprise, WPA3-Enterprise 192-bit mode, WMM, WMM-PS, PMF, WiFi Direct, WMM-AC and Voice Enterprise) |
Fast Roam
| PMKID caching; Cisco CCKM; 802.11r (Over-the-Air); OKC |
Wireless PAN
| |
Bluetooth
| Bluetooth 5.0; Bluetooth Low Energy (BLE) support; Class 1 |
| Warranty | Subject to the terms of Zebra’s hardware warranty statement, the WT6300 is warranted against defects in workmanship and materials for a period of one (1) year from the date of shipment. For complete warranty statement, |
| Recommended Services | Support Services: Maximize device availability, operational efficiency, and security updates with Zebra OneCare™ Essential or Select services. Protect your investment with depot repair or advanced device replacement, technical support, software and support, LifeGuard updates, Device Diagnostics and included cloud-based VisibilityIQ™ OneCare™ for insight into repair, case, contract, LifeGuard reports and more.
Zebra VisibilityIQ™ Foresight: With 24+ reports, this optional business intelligence service aggregates device data onto a single, color-coded, cloud-based pane of glass, letting you know how your devices are performing, so you can decide what next steps you can take to improve your operations, maximize productivity and provide actionable insight to streamline workflows.
Video on Device: Pre-loaded, it is a secure and consistent way to enable your staff with on-device training. Deliver video content to your associates with the basic VoD app that will put the right content on the palm of their hands, including how to clean and sanitize the device.
|
| Footnotes | 1. Android security updates are provided through Zebra’s LifeGuardTM for AndroidTM, a part of every Zebra support contract. A valid Zebra OneCare support contract is required to access LifeGuard’s entitlements and features.
2. Paging function is available only on supported Bluetooth peripherals that have the capability to generate a beep tone.
3. Push-to-Talk (PTT) is not supported in all countries. Please consult |
