| Physical Characteristics | |
| Dimensions | 5.22 in L x 3.66 in W x 0.55 in D
(132.5mm L x 93mm W x 13.97mm D) |
| Weight | Standard battery: 9.0 oz (254g)
Extended battery: 10.9 oz (310g) |
| Display | 4.7 inch; 720x1280; color display |
| Touch Panel | Multimode capacitive touch panel; bare or light
gloved fingertip input; Corning® Gorilla® Glass |
| Power | Standard battery: typical capacity — 3500mAh
Extended battery: typical capacity — 5000mAh |
| Network Connections | WLAN (Wi-Fi); WPAN (Bluetooth); USB 3.0 (superspeed client and host) |
| Notifications | Audible tone; multi-color LED; haptic feedback |
| Voice and Audio | Speaker; microphone; PTT voice
Buttons Power button; three (3) programmable function |
| buttons | Interface Ports One (1) USB-C (USB 3.0); two (2) charge pogo pads
on each side |
| Performance Characteristics | |
| CPU | Qualcomm® QCS4490 octa-core; 2.4 GHz |
| Operating System | Android 13; upgradeable to Android 17 |
| Memory | 6 GB RAM; 64 GB Flash |
| Security | FIPS 140-2; Secure Boot; Verified Boot |
| User Environment | |
| Operating Temp. | -4F to +122F (-20C to +50C) |
| Storage Temp. | -40F to +158F (-40C to +70C) |
| Humidity | 5% to 95%, non-condensing |
| Drop Spec. | Per MIL-STD 810H:
6 ft (1.8m) to concrete at (+73F to +122F/+23C to
+50C)
4 ft (1.2m) to concrete across temperature (-4F to
+122F/-20C to +50C) |
| Tumble Spec. | 1,000 Tumbles at 1.6 ft (0.5m) at room temperature |
| Sealing | IP65; IP67 with battery per applicable IEC sealing specifications |
| Vibration | 4g PK Sine (5Hz to 2kHz); 0.04g 2/Hz Random
(20Hz to 2kHz); 60 minutes duration per axis,
3 axis |
| Electrostatic Discharge (ESD) | +/- 15kV air discharge, +/- 8kV direct/indirect
discharge |
| Interactive Sensor Technology (IST) | |
| Light Sensor | Automatically adjusts display backlight brightness |
| Motion Sensor | 3-axis accelerometer with MEMS Gyro |
| General Certifications | |
Android Enterprise
Recommended (AER) | Yes |
| Data Capture | |
| Scanning | Compatible with Zebra wearable Bluetooth
scanners (RS2100, RS5100, RS6100) via NFC tap-topair. The RS5100 and RS6100 can be powered by
the WT5400 using the USB-C corded adapter, with
communication over Bluetooth. |
| NFC | ISO 14443 Type A and B; FeliCa and ISO 15693
cards; NFC Forum cards 1 to 5 |
| Wireless LAN | |
| Radio | IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc; 2x2
MU-MIMO; Tri-band (2.4 GHz, 5 GHz, 6 GHz); Wi-Fi
CERTIFIED 6™ (Wi-Fi 6E); Dual Band Simultaneous;
IPv4, IPv6 |
| Data Rates | 2.4 GHz: 802.11b/g/n/ax — 20 MHz - up to 286.8
Mbps; 5 GHz: 802.11a/n/ac/ax — 20 MHz, 40 MHz,
80 MHz, 160 MHz — up to 2402 Mbps; 6 GHz:
802.11ax — 20 MHz, 40 MHz, 80 MHz, 160 MHz —
up to 2402 Mbps |
| Operating Channels | Channel 1-13 (2401-2483 MHz): 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13; Channel 36-165 (5150-5850
MHz): 36, 40, 44, 48, 50, 52, 56, 60, 64, 100, 104,
108, 112, 114, 116, 120, 124, 128, 132, 136, 140, 144,
149, 153, 157, 161, 165; Channel 1-233 (5925-7125
MHz); Channel Bandwidth: 20, 40, 80, 160
MHz. Actual operating channels/frequencies
and bandwidths depend on regulatory rules and
certification agency. |
Security and
Encryption | WEP (40 or 104 bit); Enhanced Open (OWE); WPA/
WPA2 Personal (TKIP and AES); WPA3 Personal
(SAE); WPA/WPA2 Enterprise (TKIP and AES);
WPA3 Enterprise (AES); EAP-TTLS (PAP, MSCHAP,
MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2,
PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3
Enterprise 192-bit mode (GCMP256) - EAP-TLS |
| Certifications | Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED; Wi-Fi
CERTIFIED ac; Wi-Fi CERTIFIED 6 (Wi-Fi 6E); WPA2-
Personal; WPA2-Enterprise; WPA3-Personal WPA3-
Enterprise (includes 192-bit mode); Protected Management Frames: Wi-Fi Enhanced Open;
WMM (Wi-Fi Multimedia); WMM-Power Save WMMAdmission Control; Voice-Enterprise: Wi-Fi Direct;
Wi-Fi Agile Multiband; Wi-Fi QoS Management;
Wi-Fi Optimized Connectivity; Passpoint |
| Wireless PAN | |
| Bluetooth | Class 1; Bluetooth v5.3 |
| Warranty | Subject to the terms of Zebra’s hardware warranty statement, the WT5400 is
warranted against defects in workmanship and materials for a period of one (1)
year from the date of shipment. For complete warranty statement, please visit |
