| Physical Characteristics |
| Dimensions | 6.5 in. H x 2.6 in. W x 3.9 in. D
16.5 cm H x 6.6 cm W x 9.9 cm D |
| Weight | 5.7 oz. / 161.6 g |
| Input Voltage Range | 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply |
Current
| Corded DS2208-HC Operating Current at Nominal Voltage (5.0V): 250 mA (typical). (Note: Auto-Aim and Illumination on Acquiring Image) |
| Corded DS2208-HC Standby Current (idle) at Nominal Voltage (5.0V): 150 mA (typical). (Note: Auto-Aim On) |
| Color | Healthcare White |
| Supported Host Interfaces | USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485 |
| USB Certification | USB Certification |
| Keyboard Support | Supports over 90 international keyboards |
| User Indicators | Direct Decode Indicator, Good Decode LEDs, rear view LEDs, beeper (ajdustable tone and volume) |
| Performance Characteristics |
| Motion Tolerance (Handheld) | Up to 5 in./13 cm. per second for 13 mil UPC |
| Swipe Speed (HandsFree) | Up to 30.0 in./76.2 cm. per second for 13 mil UPC |
| Light Source | Aiming Pattern: Linear 624nm Amber LED |
| Illumination | (2) 645nm Super-Red LEDs |
| Imager Field or View | 32.8° H x 24.8° V nominalinal |
| Image Sensor | 640 x 480 pixels |
| Minimum Print Contrast | 15% minimum reflective difference |
| Skew Tolerance | +/- 65° |
| Pitch Tolerance | +/- 65° |
| Roll Tolerance | 0° - 360° |
Minimum Element
Resolution | Code 39 - 4.0 mil
Code 128 - 4.0 mil
Data Matrix - 6.0 mil
QR Code - 6.7 mil |
| User Environmental |
| Operating Temperature | 32.0° to 122.0° F / 0.0° to 50.0° C |
| Storage Temperature | -40.0° to 158.0° F / -40.0° to 70.0° C |
| Humidity | 5% to 95% RH, non-condensing |
| Drop Specification | Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete |
| Tumble Specification | Designed to withstand 250 tumbles in 1.5 ft./0.5 m tumbler |
| Environmental Sealing | IP52 |
| Approved Cleaners | Disinfectant Ready. Refer to the product reference guide for the complete list of approved cleaners. |
| Electrostatic Discharge (ESD) | DS2208/DS2278 and CR2278 Cradle: ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect |
| Ambient Light Immunity | 0 to 10,000 foot candles/0 to 107,600 Lux |
| Regulatory |
| Environmental | RoHS EN 50581 |
| Electrical Safety | EN 60950-1 2ed + A11 + A1 + A12 + A2:2013,
IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/
CSA-C22.2 No. 60950-1-07 |
| LED Safety | IEC 62471 |
| IT Emissions E | EN 55032 (Class B) |
| IT Immunity | EN 55024 |
| Symbol Decode Capability |
| 1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
| 2D | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro Han Xin, Postal Codes, SecurPharm |
| Symbology/Resolution | Near/Far |
| Code 39: 5 mil | 5 mil 0.2 in./0.5 cm to 6.0 in./15.2 cm |
| Code 128: 5 mil | 0.6 in./1.5 cm to 4.0 in./10.1 cm |
| PDF 417: 6.7 mil | 0.8 in./2.0 cm to 5.7 in./14.5 cm |
| UPC: 13 mil (100%) | 0.5 in./1.3 cm to 14.5 in./36.8 cm |
| Data Matrix: 10 mil | 0.3 in./0.8 cm to 6.2 in./15.7 cm |
| QR: 20 mil | 0 in./0 cm to 11 in./27.9 cm |
