| Specification |
| Item | | HT800 | HT830 |
| Printing | Printing Method | Thermal transfer | Thermal transfer |
| Resolution | 203DPI | 300DPI |
| Max. Printing Speed | 152mm/s | 100mm/s |
| Max. Printing Width | 108mm | 106mm |
| Max. Printing Length | 1200mm | 1200mm |
| CPU | 32-bit RISC CPU |
| Memory | RAM | 128MB | |
| Flash | 256MB | |
| Detection | Sensor | Out-of-paper detection, gap detection, ribbon detection, black mark
detection, cover-opening detection |
| Media | Types | Black mark label, punched hole label, folding or rolling die cutting label |
| Width | 1"(25.4mm) ‒ 4.33"(110mm) |
| Height | 0.0787"(20mm) ‒ 9.84"(250mm) |
| Thickness | 0.002"(60um) - 0.01"(250um) |
| Label Roll Diameter | 5"(127 mm)Max |
| Core Diameter | 0.5"(12.7 mm),1"(25.4 mm).1.5"(38 mm) |
| Ribbon | Type | Wax, Wax/Resin, Resin |
| Width | 2"(50mm) ‒ 4.38"(118mm) |
| Length | 984＇(300m) |
| Core Diameter | 1"(25.4 mm) |
| Programming Language | | ZPL,TSPL,EPL,DPL |
| Software | Label Design Software | HPRT BarTender Ultralite (professional and higher versions are
available for trial) |
| Driver | Windows Vista7,8,10, Server 2012/2016/2018 |
| Resident Fonts | Bitmap fonts | 6,8,12,16,32,OCR A & B. 90°,180°,270° rotatable and 10 magnification. |
| TTF fonts | CG Triumvirate™times expandable in horizontal and vertical
directions, simplified Chinese. |
| Code Pages | | DOS437,720,737,755,775,850,852,855,856,857,858,860,862,863,864,865,866,
Windows 1250,1251,1252,1253,1254,1255,1256,1257,1258,
ISO8859-1,-2,-3,-4,-5,-6,-8,-9,-15 |
| Barcodes | 1D | Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave
2 of 5, EAN-8, EAN-13, EAN-128,UPC-A, UPC-E, EAN and UPC 2 (5) digits
add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11 |
| 2D | PDF417, Maxicode, DataMatrix, QR Code, Aztec | |
| Interfaces | Standard | USB, Serial,Ethernet |
| Optional | Bluetooth 4.0/BLE, WiFi |
| Control Panel | | Two-color status light: power indicator, status indicator
Four control buttons: power button, pause button, feed button, cancel button |
| Power Supply | | Power Switch |
| Input: AC 100-240 V, 50/60 Hz |
| Output: DC 24 V / 2 A |
| Environment | Operation | 41℉(5℃) to 104℉(40℃) , humidity 30% to 85% ,non-condensing |
| Storage | -4℉(-20℃) to 122℉(50℃), humidity 10% to 90% ,non-condensing |
| Physical | Dimension(L*H*W) | 308*250*180mm |
| Characteristic | Weight | 2.8kg, excluding media |
| Options & Accessory | | Peeler module, cutter module, external label roll holder |
| Agency Approval | | CCC,CE,FCC,RoHS |
