| Brand | EPSON |
| Model | LQ-2090ll |
| Print speed | Ultra Speed Draft: 550 cps (10 cpi)
High Speed Draft: 487 cps (10 cpi)
High Speed Draft: 584 cps (12 cpi)
Draft: 366 cps (10 cpi)
Letter Quality (LQ): 121 cps (10 cpi)
Note: Normal print speed is achieved when printer safety cover is fully closed |
| Resolution | 360 x 180 dpi |
| Number of Pins | 24-pin, serial impact dot matrix |
| Character Pitch | 13 character tables
14 international countries character sets |
| Interface | Bidirectional Parallel (IEEE 1284 Nibble Mode supported)
USB 2.0 |
| Memory | 128 KB |
| Paper Size | Width
Single Sheet: 3.9" to 16.5"
Continuous: 4.0" to 16.0"
Cut-sheet Feeder: 3.9" to 16.5"
Envelopes
Envelope No.6
Envelope No.10
Length
Single Sheet: 3.9" to 16.5"
Continuous: 4.0" to 22.0"
Cut-sheet Feeder: 3.9" to 16.5"
Roll paper
8.5" width |
| Paper Capacity | Forms, continuous, multipart (original + 5 carbonless copies), 1 + 6 copies
Maximum Thickness 0.14 mm (0.0055") |
| Cartridge | Black Fabric Ribbon Cartridge - S015335
Total Print Volume : 50 million lines (not including printhead)
Ribbon life : 8 million characters, LQ 10 cpi, 48 dots/character |
| MTBF | 25,000 POH (25% duty cycle) |
| Print head life | 400 million characters, Draft 10 cpi, 14 dots/character |
| Operating System Support | Windows® 10, Windows 8, Windows 7, Windows Vista®, Windows XP, Windows Server® 2003, 2008, 2012 and 2016 |
| Noise level | 55 dBA (ISO 7779 pattern) |
| Power Supply | AC 100 V - 240 V, 50 to 60 Hz |
| Power Consumption | Operating Mode : Approx. 52 W (ISO/IEC 10561 Letter Pattern)
Ready Mode : Approx. 12 W
Sleep Mode : Approx. 0.5 W and 0.8 W (Network Model)
ENERGY STAR Compliant: Certified with V2.0 |
| - | Resident Bitmapped Fonts
Ultra High Draft: 10 cpi
High Speed Draft: 10, 12 cpi
Draft: 10, 12, 15, 17, 20 cpi
LQ: 10, 12, 15, 17, 20 cpi
Bar Code Fonts
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET, Codabar (NW-7), Industrial 2 of 5, Matrix 2 of 5
Formatting
1/6" programmable in 1/360" increments |
| Package Contents | LQ-2090II Impact Printer
Printer driver disk
Quick Installation Guide
Rear sheet guide
Power cable
Push tractor unit
Ribbon catridge - black
Warranty certificate |
| Dimensions | 24.1" x 12.6" x 6.9" (W x D x H) |
| Weight | 20.7 lb |
