Specifications |
| Part Number(s) | Infrared (Worldwide) - E268447 |
| Enclosure Color | Black |
| Touch Technology & Capacity | Infrared - 10 Touch |
| Touch Interfaces | USB |
| Diagonal Size | 54.6'' diagonal, Active matrix TFT LCD (LED) |
| Active Area (mm) | 47.6" x 26.8" / 1209.6mm x 680.4mm |
| Aspect Ratio | 16:9 |
| Resolution | External HDMI and OPS: 3840 x 2160 30Hz
External DisplayPort: 3840 x 2160 60Hz |
| Viewing Angle | Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total |
| Number of Colors | 1073.7 million |
| Brightness (typical) | LCD Panel: 450 nits
IR: 405 |
| Response Time-total (typical) | 6.5 msec |
| Contrast Ratio | 4000:1 |
| On Screen Display | Controls: Menu, Up, Down, Select, Power
Video Settings: Brightness, Contrast, VGA Settings (if available), Clock, Phase, Auto-Adjust, H-position, V-position, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Source
OSD Timer: Change between 5 and 60 seconds
Color Adjust: 9300K, 7500K, 6500K, 5500K and User mode
Color Reference: Standard, Gaming, Movie, Photo, Webcam, Blur
Saturation and Hue: In any mode other than Standard mode
Audio: From Video Source, From Line-in and ECM Line-in
Audio Controls: Mute, Volume up and Down
Video: Choose from VGA, HDMI, DisplayPort, Elo Computer Module
MDC Protocol: IIC or RS232
Black Level: Standard, 5%, 10% and 20% Offset
Light Sensor enable/disable: Sharpness Level
Aspect Ratio: Fill Screen, Fill to Aspect Ratio and Direct Output
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
Lockouts: OSD, Power
Other Settings: Power Behavior, Tabletop mode, Information, MDC Protocol, Support and Help, System Temperature and Exit
Accessible through switches on the unit's tethered OSD control box. |
| I/O Ports | Input: AC power, RJ45 Remote Connector, RS232 connector, HDMI, DisplayPort, USB type B, Audio Line In
Output: Headphone Out |
| Input Video Format | HDCP-capable HDMI on Type A connector, DisplayPort 1.1a connector |
| Input Video Frequency | Horizontal: 30 – 139.2 KHz
Vertical: 24 - 63 Hz |
| Audio Input Connector | 3.5 mm TRS jack |
| Audio Input Signal Range | 1Vrms max stereo signal (standard PC line out) |
| Headphone Output Connector | 3.5 mm TRS jack |
| Speakers | Internal 4 x 5W stereo speakers |
| Power Supply | Internal AC |
| Input Connector | IEC 60320 C14 |
| Input Voltage | 100-240VAC 50/60Hz |
| Power Consumption (Typical) | Monitor Only
(Typical at 120V at 60Hz): ON: 157 W; SLEEP: 15 W; OFF: 0.7 W
(Typical at 230V at 50Hz): ON: 156 W; SLEEP: 15 W; OFF: 0.8 W |
| Dimensions | 49.8" x 29" x 3.5" / 1267mm x 738mm x 90mm |
| Shipping Box Dimensions | 55.9" x 34.6" x 9.3" / 1420mm x 880mm x 235mm |
| Weight (Unpackaged) | Monitor Only: 100 lbs / 45.4 kg
Monitor with Computer Module: 105 lbs / 47.6 kg |
| Weight (Packaged) | Monitor Only: 121 lbs / 55 kg
Monitor with Computer Module: 126 lbs / 57.2 kg |
| Operating Temperature | Portrait/Landscape Mode: 0° C to 40° C / 32°F to 104°F
Tabletop Mode: 0° C to 35° C / 32°F to 95° F
With OPS module: 0° C to 35° C / 32°F to 95° F |
| Storage Temperature | -20°C to 50°C / -4°F to 122°F |
| Humidity | Operating: 20% to 80%
Storage: 10% to 95% |
| Mounting Options | VESA 4-hole Mount per MIS-F, 600, 600, 6mm |
| Sealability | Touchscreen sealed to bezel; Touchscreen sealed to LCD |
| MTBF | 50,000 hours demonstrated |
| Warranty | 3-year |
| Regulatory approvals and declarations | UL, FCC - Class A, cUL, IC, CB, CE - Class A, C-Tick - Class A, NOM CoC, CCC, China RoHS
With RFID: UL, FCC - Class A, CE - Class A |
| What's in the Box | QIG, JP Class A Kiosk Info, HDMI cable, DisplayPort cable, USB cable, RS232 cable, 3.5mm audio cable, power cable (NA, EU/KR, UK, AR, CH, and JP plugs), 3-pin to 2-pin adapter for JP power cable, Energy label according to EU Regulation 1062/2010 |
