| Specifications |
| Physical Characteristics |
| Dimensions |
Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D
18.5 cm H x 7.6 cm W x 13.2 cm D
Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D
18.5 cm H x 7.6 cm W x 14.2 cm D |
| Weight |
Corded: 10.8 oz./305 g; Cordless: 14.4 oz./407 g |
| Input Voltage Range |
Host powered: 4.5 VDC min., 5.5 VDC max.
External power supply: 11.4 VDC min., 12.6 VDC max. |
| Operating Current |
DS3608-DP (corded): 360 mA (RMS typical) |
| Standby Current |
DS3608-DP (corded): 100 mA (RMS typical) |
| Color |
Industrial Green |
Supported Host
Interfaces |
USB, RS232, Keyboard Wedge Industrial Ethernet: EtherNet/IP, Profinet, Modbus TCP & Std TCP/IP |
| Battery |
PowerPrecision+ 3100 mAh Li-Ion
rechargeable battery |
| User Indicators |
Direct decode indicator; LEDs; beeper; vibration |
| Performance Characteristics |
| Scans per Full Charge |
100,000+ |
| Image Capture |
Basic |
| Illumination |
Direct: Two (2) warm white light LED ;
Diffuse: Ring of red 634 nm LEDs |
| Aimer |
655 nm laser |
| Imager Field of View |
Horizontal: 31°, Vertical: 23° |
| Image Sensor |
1,280 x 960 pixels |
| Minimum Print Contrast |
15% minimum reflective difference |
| Skew/Pitch/Roll |
Skew: ± 60°
Pitch: ± 60°
Roll: ± 360° |
| decode capabilities*** |
| 1D |
Code 39, Code 128, Code 93, Codabar/NW7, Code
11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5,
GS1 DataBar, Base 32 (Italian Pharma) |
| 2D |
PDF417, Micro PDF417, Composite Codes, TLC-39,
Aztec, DataMatrix, MaxiCode, QR Code, Micro QR,
Chinese Sensible (Han Xin), Postal Codes |
| User Environment |
|
| Operating Temp. |
Corded: -22° F to 122° F/-30° C to 50° C
Cordless: -4° F to 122° F/-20° C to 50° C |
| Storage Temp. |
-40° F to 158° F/-40° C to 70° C |
| Humidity |
5% to 95% condensing |
| Drop Specification |
Withstands multiple 8.0 ft. / 2.4 m drops to concrete |
| Tumble Specification |
5,000 tumbles @ 3.3 ft. (1 m) |
| Sealing |
Scanner: IP65 and IP67;
FLB cradle: IP65 |
| ESD |
Per EN61000-4-2, ±25 KV air discharge, ±10 KV
direct discharge, ±10 KV indirect discharge |
| Ambient Light Immunity |
0 to 10,037 Foot Candles/0 to 108,000 Lux (direct sunlight) |
| UTILITIES AND MAINTENANCE |
| 123Scan |
Programs scanner parameters, upgrades firmware, provides scanned barcode data and prints reports. For more information, visit www.zebra.com/123scan |
| Scanner SDK |
Generates a fully-featured scanner application,
including documentation, drivers, test utilities and
sample source code. For more information, visit
www.zebra.com/windowsSDK |
Scanner Management
Service (SMS) |
Remotely manages your Zebra scanner and queries
its asset information. For more information, visit
www.zebra.com/sms |
| Network Connect |
Seamlessly connects 3600 Series scanners directly to your Industrial Ethernet network without any third party conversion equipment. For more information, visit www.zebra.com/NetworkConnect |
| WIRELESS CONNECTIVITY |
| Bluetooth Radio |
Bluetooth Class 1, Version 4.0 (LE), serial port (SPP) and HID profiles |
| Data Rate |
3 Mbit/s (2.1 Mbit/s) for Classic Bluetooth
1 Mbit/s (0.27 Mbit/s) for Low Energy |
| Radio Range |
Direct line of sight in open air :
Class 1: Up to 300 ft. (100.0 m)
Class 2: Up to 30 ft. (10.0 m) |
| Regulatory |
| Environmental |
RoHS EN 50581: 2012 |
| Electrical Safety |
EU Safety: EN 60950-1: 2006 + A11: 2009 + A1:
2010 + A12: 2011 + AC 2011 + A2: 2013; International
Safety: IEC 60950-1: 2005 + A1: 2009 + A2: 2013
US/Canada Safety: UL 60950-1, second edition,
CAN/CSA-C22.2 No. 60950-1-07 |
| Laser/LED Safety |
Exempt Risk Group LED per IEC/EN 62471 (Ed 1) Class 2 Laser per IEC/EN 60825-1 (Ed 3) Complies with 21CFR1040.10 |
| EMI/RFI |
IT Emissions: EN 55022: 2010/AC: 2011 (Class B); IT Immunity: EN 55024: 2010; Heavy Industrial: EN 61000-6-2: 2005/AC:2005; Harmonic Current Emissions: EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 (Class B); Voltage Fluctuation and Flicker: EN 61000-3-3: 2013; Medical Electrical Equipment: EN 60601-1-2: 2007/AC: 2010, IEC 60601-1-2: 2007 (Modified); Radio Frequency Devices: 47 CFR Part 15, Subpart B, Class B Digital Apparatus: ICES-003 Issue 5, Class B |
