Specifications
|
| Printer Method |
25 Pin Serial Impact Dot Matrix |
| Print Speed |
3 Receipts Per Minute (4.7 Lines Per Second at 42 Columns) |
| Printer Case Color |
Gray |
| Models Available |
Tear Bar or Auto Cutter without Rewinder
Tear Bar or Auto Cutter with Rewinder
|
| Two Color Print Capability |
Red & Black Ribbon Required - RC700BR |
| Print Font |
|
Font Size
Character Size
Character Set
Code Pages
Character Per Inch
|
5 x 9 / 7 x 9
1.2 (W) x 2.42 (H) / 1.5 (W) x 2.42 (H) mm
95 Alphanumeric, 32 International
40
16.9 / 14.1
|
| Line Spacing |
1/6 inch Standard |
|
Paper Specifications
Width
|
76mm standard, Adjustable 69.5mm or 58mm with paper guide
|
|
Roll Diameter
Thickness 1 Ply Paper
Copy Capability 2 Ply
Copy Capability 3 Ply
Easy-Load
Paper Out Sensor
Paper Low Sensor
Print Width
|
Up to 85mm
0.065 ~ 0.085mm
Original + 1, 0.05-0.08 / piece, total less 0.14
Original + 2, 0.05-0.08 / piece, total less 0.20
"Drop-In & Print"
Standard
Optional
63mm, 57mm, 45mm
|
| Ribbon Specifications |
| RC700B |
Black (3,000,000 Characters) |
| RC700BR |
Black/Red (1,500,000 / 750,000 Characters) |
| RC700D |
Indelible Black Ribbon (Laundry Applications) |
| Auto Cutter |
Guillotine (Partial Cut Only) |
| Cover Open Sensor |
Yes |
| Program ROM |
Flash Memory (16 Mbit), NV bit image 256 KB
|
| Multiple Copy Support |
Original + 2 Copies Maximum |
| Journal Capability |
Yes; Rewinder model required |
| Label Support |
N/A |
| Power Supply |
Internal; Power cable included in box |
| Drivers Available |
Windows 10, Windows 8.1, Windows® XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit,
XP Embedded, POSReady 2009, OPOS™, JavaPOS™, USB Vendor Class, Linux™, Mac OS X, StarIO SDK with
support for iOS, Android and Blackberry
|
| Digitally Signed (WHQL) |
Yes |
| Swappable Interfaces |
Yes |
| Connectivity |
Apple MFi Certified Bluetooth, WebPRNT, WebPRNT Browser App, Serial, Parallel, USB, Ethernet |
| Emulation Modes |
Star Mode, ESC/POS™
|
| Peripheral Drive Circuit |
2 Drivers |
| Power Consumption |
Average 36W, Printing, 10W
|
| Operating Conditions |
Temerature: 0oC to 50oC
Humidity: 0% - 90% RH (without condensation)
|
| Storage Conditions |
Temerature: -20oC to 70oC
Humidity: 5% - 95% RH
|
|
Dimensions
|
|
Non-Rewinder Models
|
160 x 152 x 245 (W x H x D)mm |
|
Rewinder Models
|
164 x 152 x 245 (W x H x D)mm
|
|
Weight
|
| Tear Bar Model |
2.96 kg |
| Auto Cutter Model |
3.18 kg |
| Tear Bar Rewinder Model |
3.43 kg |
| Auto Cutter Rewinder Model |
3.65 kg |
|
Safety Standards
|
UL, C-UL, TuV, CB, FCC Class A, VCCI Class A, EN55022, CE
|
|
Reliability MCBF
|
22 Million Lines
|
| Print Head |
150 Million Characters |
| Auto Cutter |
1 Million Cuts |
|
Accessories All Included with Printer
|
Installation CD with Drivers, Configuration Utility, and Value Add Utility modeled after futurePRNT Software,
Set Up Guide, Power Cord, Embedded Power Supply, Vertical Mount Accessory, Paper Guide, Power Switch
Cover, Start-Up Ribbon
|
|
Options
|
Kitchen Buzzer (BU01-24-A)
Wall Mount Bracket (WB-S700)
Vertical Stand Kit (VS-S700)
Near End Paper Sensor
Swappable Interfaces
Swap-A-Star Extended Warranty Program (US)
Extend-A-Star Extended Warranty Program (US and Canada)
|
