SPECIFICATIONS |
PACKAGE INCLUDES: |
• Poly Studio X30 • Cable bundle • Monitor clamp • Privacy cover |
VIDEO STANDARDS AND PROTOCOLS |
• H.264 AVC, H.264 High Profile, H.265 |
VIDEO INPUT |
• 1x HDMI |
VIDEO OUT |
• 1x HDMI • Touch display compatible |
PEOPLE VIDEO RESOLUTION |
• 4K, 30 fps (TX and RX) from 2048 Kbps • 1080p, 60 fps from 1740 Kbps • 1080p, 30 fps from 1024 Kbps • 720p, 60 fps from 832 Kbps • 720p, 30 fps from 512 Kbps |
CONTENT VIDEO RESOLUTION |
• Input - UHD (3840 x 2160) - HD (1920 x 1080p) - WSXGA+ (1680 x 1050) - UXGA (1600 x 1200) - SXGA (1280 x 1024) - WXGA (1280 x 768) - HD (1280 x 720p) - XGA (1024 x 768) - SVGA (800 x 600 • Output - UHD (3840 x 2160) - WUXGA (1920 x 1200) - HD (1920 x 1080) - WSXGA+ (1680 x 1050) - SXGA+ (1400 x 1050) - SXGA (1280 x 1024) - HD (1280 x 720) - XGA (1024 x 768) • Content frame rate - 5–60 fps (up to 4K resolution at 15 fps in call) |
CONTENT SHARING |
• Poly Content App support • Apple Airplay • Miracast • HDMI input • Whiteboarding |
CAMERA |
• 4x digital zoom • 120° FOV • UHD 2160p (4K) capture resolution • Automatic people framing • Automatic speaker tracking |
AUDIO INPUT |
• Four MEMS microphones • Microphone pickup range 15 ft |
AUDIO OUTPUT |
• Single Speaker |
OTHER INTERFACES |
• 1x USB-A (3.0) • 1x USB-C • Bluetooth 5.0 • WiFi 802.11a/b/g/n/ac (MIMO) Multi-channel Concurrency |
AUDIO STANDARDS AND PROTOCOLS |
• 22 kHz bandwidth with Polycom Siren 22 technology • 20 kHz bandwidth with G.719 (M- Mode) and Polycom Siren 22 technology • 14 kHz bandwidth with Polycom Siren 14 technology, G.722.1 Annex C • 7 kHz bandwidth with G.722, G.722.1 • 3.4 kHz bandwidth with G.711, G.728, G.729A |
NETWORK |
• IPv4 • IPv6 • 1x 10/100/1G Ethernet • Auto-MDIX • H.323 and/or SIP up to 6 Mbps in Poly App video mode • Polycom Lost Packet Recovery (LPR) technology • Dynamic bandwidth allocation • Reconfigurable MTU size • Web proxy support—basic, digest, and NTLM • Simple Certificate Enrollment Protocol (SCEP) |
SECURITY |
• Media Encryption (H.323, SIP): AES-128, AES-256 • H.235.6 support • Authenticated access to admin menus, web interface, and APIs • Local account password policy configuration • Security profiles • Local account and login port lockout • Secure defaults • Remote logging with support for TLS • Active directory external authentication |
OPTIONS |
• VESA and wall mount kit • Stand • Poly TC8 • Poly Bluetooth remote control • Poly Trio • Inverted mount kit |
INTEROPERABILITY |
• Zoom Certified • Microsoft Teams Certified • All cloud service providers through Poly Video App mode • USB Device Mode • Support for native 3rd party applications includes Zoom, Microsoft Teams, 8x8, GoToRoom, RingCentral and StarLeaf |
ELECTRICAL |
• Auto sensing power supply • Typical operating voltage/power - 37 VA @ 120 V @ 60 Hz - 37 VA @ 230 V @ 50/60 Hz • Typical BTU/h: 65 |
ENVIRONMENTAL SPECIFICATION |
• Operating temperature: 0 to 40 °C • Operating humidity (non-condensing): 15 to 80% • Non-operating temperature: -40 to 70 °C • Non-operating humidity (non-condensing): 5 to 95% • Maximum altitude: 16,000 ft |
PHYSICAL CHARACTERISTICS |
• 17.39 W x 2.46 H x 2.42 D (inches) 441.8 W x 62.5 H x 61.6 D (mm) • 1.6 lbs/.73 kg |
WARRANTY |
• One-year return to factory parts and labor |
