| Specifications |
| Colour Options |
Pro1040 (CMYK) |
| Media Type2 |
Plain Paper, Film, Plain Paper Label, Glossy Paper Label, Synthetic Film Label |
| Media Width |
Roll paper: 29.4mm (1.16″) – 130mm (5.1″) including liner |
| Media Thickness |
0.076 – 0.250mm |
| Label Length |
12.7mm (0.5″) – 1320.8mm (52″) |
| Label Width |
25.40 – 125.76mm |
| Media Detection |
Black Mark (printed on back of liner), Gap, None |
| Media Format |
Roll |
| Roll Outer Diameter / Core Inner Diameter |
Max. Ф203.2mm (Φ8″) / Ф76.2mm (Φ3″ |
| Roll Wind Direction |
Face-out, Face-in |
| Print Width |
Max. 125.76mm |
| Minimum Print Margin |
Top: 2.12mm, Bottom: 2.12mm, Right: 2.12mm, Left: 2.12mm |
| Print Position Accuracy / Cut Accuracy |
Vertical: ±0.5mm, Horizontal: ±0.5mm / Vertical: ±0.5mm |
| Cuttable Media Length |
Min. 101.6mm |
| Print Resolution |
1200 x 1200 dpi, 600 x 600 dpi |
| Print Speed |
Max. 152.4mm/s (6ips) |
| Interface |
1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed), USB 2.0 (High Speed) Host, |
| Protocol |
TCP/IP, IPX/SPX, EtherTalk |
| Printer Language |
Adobe PostScript3 , PCL 5c emulation, PCL 6 (XL) emulation |
| Supported OS |
Windows 10, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008,
Windows Server 2008 x64, Windows 10 x64, OS X 10.10, Windows 8.1, Windows 8.1 x64, OS X 10.11, Windows Server
2016, macOS 10.12, Windows 8, Windows 8 x64,Windows 7, Windows 7 x64
|
| Processor Speed |
ARM 1.2 GHZ |
| Memory (Std./Max) |
2,000 MB / 2,000 MB |
| Hard Disk Drive |
250 GB |
| Auto Cutter |
Rotary blade full cut |
| Dimensions (WxDxH) |
1,049 x 341 x 451 mm (printer with unwinder) |
| Weight (includes supplies) |
Approx. 60.0 kg (printer with unwinder) |
| Toner / Image Drum Life (C,M,Y,K) |
9K Pages (A6 20% coverage each colour) |
| Transfer Belt / Fuser Life |
150K Pages (approx 22km of labels @A6 pages) |
| Waste Toner Box Life |
50K Pages |
