| Specifications |
| Printer Specifications |
| Print Method |
Thermal Transfer, Direct Thermal |
| Print Speed |
Print Speed SLP-TX400: Up to 7 ips (178 mm/sec) SLP-TX403: Up to 5 ips (127 mm/sec) |
| Print Resolution |
SLP-TX400: 203 dpi SLP-TX403: 300 dpi |
| Print Width |
SLP-TX400: Up to 108 mm SLP-TX403: Up to 105.7 mm |
| Sensor |
Transmissive, Reflective (Adjustable), Ribbon-End, Head open |
| Media Characteristics |
| Media Type |
Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width |
25 ~ 112 mm |
| Media Roll Diameter |
Up to 130 mm |
| Media Thickness |
0.06 ~ 0.20 mm |
| Supply Method |
Easy Paper Loading |
| Ribbon Characteristics |
| Ribbon Type |
Wax, Wax/Resin, Resin, Outside |
| Ribbon Width |
33 ~ 110 mm |
| Ribbon Length |
Up to 300 m |
| Core Inner Diameter |
25.4 mm, 12.5 mm |
| Physical Characteristics |
| Dimensions (WxDxH) |
214 x 310 x 195 mm (8.42 x 12.20 x 7.67 inch) |
| Weight |
2.85 kg (6.28 lbs.) |
| Power |
EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz |
| Performance Characteristics |
| Memory |
64 MB SDRAM, 128 MB Flash |
| Interface Options |
Standard: USB + Serial + Parallel Optional: USB + Serial + Ethernet + WLAN¹ |
| Environment Characteristics |
| Temperature |
Operating: 5 ~ 40℃ (41 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉) |
| Humidity |
Operating: 10 ~ 80% RH Storage: 10 ~ 90% RH |
| Fonts / Graphics / Symbologies |
| Fonts |
One SLCS Resident Scalable Font • 16 BPL-Z™ Resident Bitmap Fonts • One BPL-Z™ Resident Scalable Font • 5 BPL-E™ Resident Bitmap Fonts • 23 Code Page • Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
| Graphics |
Supporting user-defined fonts, graphics, formats, and logos |
| Barcode Symbologies |
1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
