| Printing Method |
Direct Thermal & Thermal Transfer |
| Printing Resolution |
300 dpi (12 dots/mm) |
| Printing Speed |
Max. 4 ips |
| Printing Length |
Max. 50”(1270 mm) |
| Printing Width |
Max. 4.16”(105.7 mm) |
| Memory |
128MB SDRAM, 128MB Flash ROM (USB storage up to 32GB) |
| CPU Type |
32 bit RISC microprocessor |
| Sensors |
Reflective sensor x 1 (movable) & Transmissive sensor x 1 (fixed, 6.27mm offset) |
| Operation Interface |
LED Indicator x 2, Button(Feed) x 1 |
| Communication Interface |
USB device, RS-232, Ethernet, USB host |
| Fonts |
Internal character sets standard, 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation. Soft fonts are downloadable Ability to print any Windows True Type font easily. Support scalable font. GB 18030 Standard (Chinese coded character set) suppor |
| Wireless Security |
N/A |
| 1D Barcodes |
PPLA: Code 39、UPC-A、UPC-E、Code 128 subset A/B/C、EAN-13、EAN-8、HBIC、Codabar、Plessey、UPC2、UPC5、Code 93、Postnet、UCC/EAN-128、 ,UCC/EAN-128 K-MART、 UCC/EAN-128 Random weight、Telepen、FIM、Interleaved 2 of 5 (Standard/with modulo 10 checksum/ with human readable check digit/ with modulo 10 checksum & shipping bearer bars) 、GS1 Data bar (RSS) PPLB: Code 39、 UPC-A、 UPC-E、 Matrix 2 of 5、 UPC-Interleaved 2 of 5、Code 39 with check sum digit 、Code 93、EAN-13、EAN-8 (Standard, 2 /5digit add-on) 、Codabar、Postnet、Code128 subset A/B/C、Code 128 UCC (shipping container code) 、Code 128 auto、UCC/EAN code 128 (GS1-128) 、 Interleave 2 of 5、Interleaved 2 of 5 with check sum、Interleaved 2 of 5 with human readable check digit、German Postcode、Matrix 2 of 5、 UPC Interleaved 2 of 5、 EAN-13 2/5 digit add-on、 UPCA 2/5 digit add-on、UPCE 2/5 digit add-on、GS1 Data bar (RSS) PPLZ: Code39、 UPC-A、 UPC-E、 Postnet、 Code128 subset A/B/C、Interleave 2 of 5、Interleaved 2 of 5 with check sum、Interleaved 2 of 5 with human readable check digit、Code 93、Code 39 with check sum digit、MSI、EAN-8、Codabar、Code 11、EAN-13、Plessey、GS1 Data bar (RSS) 、 Industrial 2 of 5、 Standard 2 of 5、 Logmars |
| 2D Barcodes |
MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec |
| Graphics |
PPLA: PCX, BMP, IMG, HEX,GDI
PPLB: PCX, BMP, Binary raster, GDI
PPLZ: GRF, Hex, GDI |
| Emulation |
PPLA, PPLB, PPLZ, Auto |
| Software-label Editing |
BarTender® from Seagull Scientific Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf) |
| Software-utility |
BarTender, Printer Tool, Font Utility, iLabelPrint+ |
| Driver tools |
Windows Vista/Win7/Win8/Win10, LINUX Driver, macOS Driver, Raspberry Pi Driver |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper |
| Media |
Max. width: 4.65” (118mm). Min. width: 0.88” (22.4mm). Thickness: 0.0024”~0.0075” (0.06mm~0.19mm) 5”(127mm) OD on a 1”/1.5” (25.4/38 mm) ID core; Dealer Option external media stand 8” OD on 1”/3” ID Core |
| Ribbon |
Ribbon width: 1.6”~4.33”(40 mm~110mm), Ribbon length: Max. 300m. Core size ID 1”(25.4 mm) or 0.5”(12.7mm) Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect) |
| Drop Resistance |
N/A |
| Printer Dimensions |
W 220.6mm x H 187.5mm x D 278.5mm |
| Printer Weight |
2.4 kgs |
| Power Source |
Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 24V, 3.75A |
| Battery |
N/A |
| Operation Environment |
Operation Temperature: 41°F~104°F (5°C~40°C), 0% ~ 90% non-condensing Storage Temperature: -4°F~140°F (-20°C~60°C) |
| Real Time Clock |
N/A |
| Standard Item |
N/A |
| Optional Items |
Guillotine-Full Cutter / Partial Cutter, Dispenser , External media stand, Bluetooth v4.2, WLAN |
| Agency Listing |
CE, FCC, IC, CB, UL, RoHs, BSMI |
| Attention |
*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications. |
