| Printing Method |
Direct Thermal & Thermal Transfer |
| Printing Resolution |
203 dpi(8 dots/mm) |
| Printing Speed |
Max. 6 ips |
| Printing Length |
Max. 100”(2540mm) |
| Printing Width |
Max. 6.6”(168mm) |
| Memory |
32 MB SDRAM, 16MB Flash ROM (USB storage up to 32 GB) (FAT32 format) |
| CPU Type |
32 bit RISC microprocessor |
| Sensors |
Reflective sensor x 1 (Movable) & Transmissive sensor x 1(Movable) |
| Operation Interface |
LED Indicator x 3, Button(Feed) x 3, LCD Display x 1 |
| Communication Interface |
USB device, RS-232, Ethernet, USB host x 2 |
| Fonts |
Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation Soft fonts are downloadable Ability to print any Windows True Type font easily Support scalable font |
| Wireless Security |
N/A |
| 1D Barcodes |
UPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirecional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked |
| 2D Barcodes |
QR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode |
| Graphics |
PPLA: PCX, BMP, IMG, HEX,GDI PPLB: PCX, BMP, Binary raster, GDI PPLZ: GRF, Hex, GDI |
| Emulation |
PPLA, PPLB, PPLZ |
| Software-label Editing |
BarTender® from Seagull Scientific Argobar Pro support ODBC Database Connection: Excel, CSV, MS Access, MS SQL, Oracle MySQL, dBASE (*.dbf) |
| Software-utility |
Printer Tool |
| Driver tools |
Argox Seagull Driver (Windows Vista/Win7/Win8/Win10) Argox Linux Printer Driver Argox macOS Printer Driver Argox RPi Printer Driver |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper |
| Media |
Max. width: 6.8” (173mm) Min. width: 2” (50.8 mm) Thickness:0.0025”~0.01” (0.0635mm~0.254mm) 8.26”(210mm) OD on a 3”(76mm) ID core 7”(177.8mm) OD on a 1.5”(38mm) ID core |
| Ribbon |
Width: 2”~6.78”(50.8 mm~172 mm) Length: max 450m Wax, 450m Semi-Resin Max OD 3.2” (81.3 mm) Core size ID 1” (25.4 mm) Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in) |
| Drop Resistance |
N/A |
| Printer Dimensions |
W 318mm x H 262mm x D 470 mm |
| Printer Weight |
14 kgs |
| Power Source |
Internal Universal Switching Power supply. Input voltage: 100~240V, 50~60Hz |
| Battery |
N/A |
| Operation Environment |
Operation Temperature: 40°F~104°F (4°C~40°C), 25% ~ 85% non-condensing Storage Temperature: -4°F~122°F (-20°C~50°C) |
| Real Time Clock |
N/A |
| Optional Items |
Cutter, Peeler, WLAN, GPIO, Parallel module, Rewinder kit |
| Agency Listing |
CE, CB/LVD, FCC, ICES, BSMI |
| Attention |
*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications. |
